Product Description
- The Sealey PDM125B is a 16-speed bench pillar drill designed for professional workshop applications, offering precise drilling operations with comprehensive safety
- .
- Part of Sealey's Premier range, this bench-mounted pillar drill delivers reliable performance for engineering workshops, fabrication shops, and maintenance facilities requiring accurate metalworking capabilities.
- Featuring a high-torque aluminium-bodied induction motor, this pillar drill provides 16 speed settings spanning 190-3000rpm, enabling operators to match drilling speeds precisely to material types and bit sizes.
- The substantial 165mm spindle centre to column distance and 330mm swing capacity accommodate a wide range of workpiece sizes, whilst the 80mm spindle travel and MT2 taper spindle nose with 16mm chuck capacity handle demanding drilling tasks with precision.
- Safety has been engineered throughout this professional-grade machine.
- The no-volt release switch prevents inadvertent start-up after power interruptions, whilst the pulley cover
- a microswitch that prevents operation when open.
- An electrically interlocked chuck guard provides additional protection during drilling operations, meeting the safety requirements expected in commercial workshop environments.
- The large 254 x 254mm square working table incorporates precision rack and pinion height adjustment for accurate workpiece positioning, with a maximum spindle to table distance of 485mm.
- The robust construction is reflected in the 45kg nett weight and substantial 450 x 270mm base, providing the stability essential for precision drilling operations.
- Backed by a 3-year guarantee, this 230V bench pillar drill represents dependable equipment for professional engineering and metalworking applications.
- 16-speed range (190-3000rpm) for optimal drilling performance across different materials
- No-volt release switch and microswitch-protected pulley cover for enhanced operator safety
- Electrically interlocked chuck guard provides additional protection during operation
- Large 254 x 254mm square table with precision rack and pinion height adjustment
- Heavy-duty aluminium-bodied induction motor for long-term reliability
- 165mm spindle centre to column with 330mm swing for versatile workpiece capacity
- MT2 taper spindle nose with 16mm chuck capacity for secure bit retention
- 3-year guarantee providing peace of mind for professional users
- Base Size: 450 x 270mm
- Brand: Premier
- Collar Diameter: Ø55mm
- Column Diameter: Ø73mm
- Drilling Capacity (Chuck Size): 16mm
- Integral Work Light: No
- Maximum Distance Spindle to Base: 700mm
- Maximum Distance Spindle to Table: 485mm
- Motor Power (Start): 370W(600W)
- Nett Weight: 45kg
- Number of Speeds: 16
- Optional Accessories: PDM/KC
- Keyless Pillar Drill Chuck 16mm
- Overall Height: 1050mm
- Speed Range: 190-3000rpm
- Spindle Centre to Column: 165mm
- Spindle Nose Taper: MT2
- Spindle Travel: 80mm
- Supply: 230V
- Swing: 330mm
- Working Base Surface Size: 205 x 200mm
- Working Table Surface Size: 254 x 254mm
Specifications
| Brand Id | 14536 |
|---|---|
| Delivery Cost | £11.85 |
